Formax AutoSeal FD 2096 High Volume Production Pressure Sealer

Basic Specs of the Formax AutoSeal FD 2096 Pressure Sealer

• Hopper Capacity: Up to 350 sheets 24#
• Variable Speed: Up to 30,000 forms per hour
• Usage: Mid-Volume Production
• Paper Size: Up to 12” wide, up to 17” long
• Dimensions (Conveyor Extended): 86” L x 28” W x 42” H
• Dimensions (Conveyor Closed): 64” L x 28” W x 42” H
• Weight: 450 lbs.
• Power: 120V 60Hz, 30Amp, single phase
• Power Plug: NEMA L5-30P

Features of the Formax AutoSeal FD 2096 Pressure Sealer

• Process up to 30,000 forms per hour.
• Bottom-suction air feed deck allows for continuous loading.
• Accepts paper sizes up to 12" wide by 17" long.
• Metal fold plates have standard and metric markings for easy set-up.
• Insulated fold plate covers for quieter operation.
• 6-digit LED resettable counter.
• Space saving 24" outfeed conveyor folds down when not in use.
• Available options are the 402 Jogger, V-Stack 36 Stacker, and Center Slitter.

Description of the Formax AutoSeal FD 2096 Pressure Sealer

The AutoSeal FD 2096 uses patented pressure seal technology to efficiently process cut-sheet pressure seal forms in a mid-volume production environment, at speeds of up to 30,000 forms per hour. Its bottom-suction air-feed system provides accurate feeding and allows for continual loading of forms, dramatically reducing down time.

Setting up the AutoSeal FD 2096 is quick and easy with rugged metal fold pates, clearly marked with standard and metric markings. The sealing unit utilizes an adjustable 17” 8-ball transport deck for a smooth transition from the fold rollers into the sealer. Other features include user-friendly operator controls, sound-dampening fold plate covers for quieter operation, rugged locking casters, and a high-capacity 24” output conveyor which is collapsible for convenient storage.
