Martin Yale 1217A AutoFolder Folding Machine
- SKU: MYL1217A
- Max Paper Weight: 200 gsm
- Max Paper Size: 11.37" x 18"
- Adjustment: Manual
- Feed Type: Friction
- Fold Types: Letter, Half, Z-fold, Double Parallel, Gate, Engineer, Church
- GTIN/UPC: 00011991012170
- Mfr. Part No.: 1217A
- Sale price
- Sale price
- $1,785.41
- Unit price
- per
Call us at (800) 243-9226
FREE GROUND SHIPPING within the contiguous U.S.
The Martin Yale 1217A medium duty auto folder is one of the most popular folding machines for churches, schools, home and small offices, and small to medium sized mailrooms. This machine is built for reliability, convenience, and overall longevity. Constructed with high impact steel side frames, this paper folder was designed with dependability in mind.
Basic Specs of the Martin Yale 1217A Paper Folder
- Feed Tray Capacity: Up to 250 sheets
- Paper Weights: 16 lb. to 90 lb. cover; 60 gsm to 240 gsm
- Standard Paper Size: 4" x 4" to 12" x 18"
- Fold Types: Letter, Half, Z-fold, Double Parallel, Gate, Engineering, Church
- Benchmark Speed: 10,300 sheets/hour
Features of the 1217A Martin Yale Paper Folding Machine
- Fully modifiable fold plates and a sturdy exit conveyor belt system.
- First fold adjustable within a 2" to 11.5" range.
- Second fold adjustable within a 1.5" to 5.75" range.
- Fully equipped to customize a second folding pass.
- Rubber rollers create neat and even professional folds every time.
- Excellent longevity and durability.
Fold Types for the Martin Yale 1217A
There are seven different fold types available for the 1217A:
(1) Letter fold (Tri-fold, C-fold),
(2) Half-fold (Single fold),
(3) Z-fold (Accordion, Zig Zag),
(4) Double-Parallel,
(5) Gate (Open Gate, Brochure),
(6) Engineering (Short Z, Fold Out, Half Accordion), and
(7) Church (Right Angle fold).
(1)
(2)
(3)
(4)
(5)
(6)
(7)
Videos of the 1217A Manual Paper Folder
Description of the 1217A Manual Paper Folder
The Martin Yale 1217A Medium Duty Auto Folder is one of the most popular folding machines for churches, schools, and medium to large mailrooms on the market. This machine is built for reliability, convenience, and overall longevity. Constructed with high impact steel side frames this paper folder was designed with sturdiness and dependability in mind. Made in the USA, Martin Yale also guarantees the durability and lifespan of any of their machine's part for one full year and will replace or repair any parts broken under normal use.
The 1217A folder is 21.25" tall, 17" wide, 13" deep, and 64 pounds. While this model is larger than other popular paper folders, the 1217A compensates with a wide array of other convenient features not available on other models. For example, the 1217A folds up to 10,300 sheets per hour, much faster than the 1501X AutoFolder. It also has a 250 sheet feed tray capacity and takes paper sizes from 4"x4" to 12"x18", which includes the standard letter size and legal sized paper.
This model has four standard folds: letter, half, z-fold, and double parallel, but it also has easily adjustable fold plates for custom folds. In fact, it has an adjustable fold range of 2" and 11.5" for the first fold and 1.5" and 5.75" on the second fold. In addition, this paper folder is capable of folding multiple papers (generally stapled) simultaneously and is fully adjustable for a second folding pass with the manual bypass.
The 1217A Auto Folder also comes with a 3 conveyor belt system which feeds the papers into the machine and dispenses them in neatly fanned stacks, preventing nesting and allowing for convenient and easy handling. The large rubber rollers also provide consistent paper feeding and produces a tight, finished fold.
Another convenient feature of the 1217A Paper Folder is the reversible motor. This feature was pioneered by Martin Yale and the 1217A is still one of the few folding machines with this feature. The reversible motor allows the user to prevent and fix paper jams, extending the life of the machine and saving the user time and frustration.
Overall, the Martin Yale 1217A Paper Folder is one of the best deals on the market. It has all the basic features as well as some additional convenient specifications, all for a very reasonable price. The durability and user friendliness of the 1217A paper folding machine is what makes this model one of the most popular folding machines for organizations such as businesses, nonprofits, schools, and churches.
Proper maintenance is the key to extending the life of your paper folding machine. We strongly advise that you protect your investment by adding the 1217A paper folder maintenance kit to your cart.
Please select your preferred download file from the list below.
- Spec Sheet for the Martin Yale 1217A (PDF file)
- Instruction Manual for the Martin Yale 1217A (PDF file)
- Parts Diagram for the Martin Yale 1217A (PDF file)
- Instructions for Replacing the Feed Wheel/Roller for the Martin Yale 1217A (PDF file) (only for models whose serial number is above 50000 and/or serial number beginning with 39565)
For additional resources, please see:
- Our Paper Weight Conversion Chart for paper weight and paper stock information.
- Our Paper Folder Fold Type Guide to learn more about different fold types.
Warranty: For this paper folding machine, Martin Yale's general warranty is 180-days parts and labor. Some restrictions and conditions may apply.
| Manufacturer Name | Martin Yale |
|---|---|
| Model # | 1217A |
| Feed Type | Friction-fed |
| Fold Adjustment Setting | Manual fold adjustment |
| Feed Tray Capacity | Up to 250 |
| Fold Speed | 10,300 sheets/hour |
| Fold Types | Half Fold, Letter Fold (Tri), Z Fold, Double Parallel Fold, Right Angle Fold, Baronial Fold |
| Pre-programmed Standard Folds | 6 |
| Accepted Paper Sizes | 3 1/2" x 4" to 11 3/4" x 18" |
| Accepted Paper Weights | 18 lbs. index to 135 lbs. index (60 gsm to 240 gsm) 16 lb bond to 90 lb cover (60 gsm to 240 gsm) |
| Product Weight | 59 lbs. |
| Product Dimensions (WxDxH) | 21" x 15.5" x 13.2" |
| Voltage | 115 Volts; other voltages available |
| Warranty | Click here to view warranty |
| UPC | 011991012170 |
| Shipping Weight | 64 lbs. |
| Shipping Dimensions | 23" x 28" x 20" |
Please see the frequently asked question(s) below. If you can't find the answer to your question, feel free to give us a call at (800) 243-9226.
Is the Martin Yale 1217A offered as a new, refurbished or remanufactured machine?
This is a brand new machine, direct from the manufacturer.
QUESTIONS & ANSWERS
Ask a Question-
Can this machine fold documents with staples? Staples on the top left or a multi fold with staples on left side?
Can it? Absolutely. But over time staples will wear ridges in the fold rollers and require replacement at highly accelerated rates. This applies to every paper folder and folder-inserter on the market, paper processing equipment just doesn't handle staples well.
-
What size fuse is needed for this unit? Mine keeps blowing each time I start it...
That's not normal behavior for a 1217A. If you contact our parts department at 301-354-3000 then they'll be able to assist with quoting fuses, but there's a broader problem occuring here that could be related to the machine, or it could be related to your power source.
