Martin Yale 1811 AutoFolder Paper Folder (Discontinued)

  • SKU: MYL1811
  • Max Paper Weight: 240 g/m²
  • Max Paper Size: 11.75" x 18"
  • Adjustment: Manual
  • Feed Type: Friction
Sale price
Limited availability.
Sale price
$2,024.00
Unit price
per

This product has been discontinued by the manufacturer. The new model that we recommend is the Martin Yale 1812 Paper Folding Machine. If you have any questions, please click the Request a Quote button below, or call us at (800) 243-9226.

Request A Quote
Need Advice?
Call us at (800) 243-9226

The Martin Yale 1811 paper folding machine automatically folds your documents with the push of a button. It is a fantastic choice for those that want the freedom and flexibility of adjusting the fold plates manually. It is an ideal folding machine for mailrooms, offices, churches, schools, businesses and associations.

Basic Specs for the Martin Yale 1811 Folder

  • Feed Tray Capacity: Up to 300 sheets
  • Paper Weights: 16 lb bond to 135 lb index; 60 gsm to 240 gsm
  • Standard Paper Size: 5" x 5" to 11.69" x 17"; A3, A4, A5
  • Fold Types: Letter, Half, Z-Fold, Double Parallel, Gate, Engineering, Church
  • Feed Type: Friction
  • Fold Plate/Table Adjustment: Manual
  • Benchmark Speed: 12,000 sheets/hour

Features of the 1811 Martin Yale Folder

  • Automatically feeds, folds and collects a stack of documents.
  • Folds stapled or unstapled sets of up to 5 sheets through manual bypass.
  • Adjustable 1st fold range of 2" to 11.5"
  • Adjustable 2nd fold range of 1.5" to 5.75" allowing for customized folds.
  • Fully enclosed, manually adjusted fold tables for quieter operation and improved operator safety.
  • Can feed wide range of paper weights without having to adjust the feed system.
  • Large rubber rollers provide consistent paper folding.

Fold Types for the Martin Yale 1811

There are seven different fold types available for the 1811: (1) Letter fold (Tri-fold, C-fold), (2) Half-fold (Single fold), (3) Z-fold (Accordion, Zig Zag), (4) Double-Parallel, (5) Gate (Open Gate, Brochure), (6) Engineering (Short Z, Fold Out, Half Accordion), and (7) Church (Right Angle fold).

(1)Letter/Tri/C Fold (2)Half/Single Fold (3)Z/Accordion Fold (4)Double Parallel Fold (5)Gate/Brochure Fold (6)Engineer Fold (7)Church/Right-Angle Fold

We strongly advise you properly maintain your paper folding machine - please see our Martin Yale 1811 Maintenance Kit for more information.

Video of the Martin Yale 1811 Paper Folder


Description of the Martin Yale 1811 Paper Folder

Martin Yale once again proves why their paper folders are used by so many organizations from churches and schools to offices. The Martin Yale 1811 Paper Folder is built to handle paper sizes from 5” x 5” all the way up to 11.75” x 18”, it automatically feeds, folds and stacks up to 12,000 sheets per hour. It offers 7 different fold types: Letter, Half, Z, Double Parallel, Gate, Engineering and Church, as well as the ability to customize folds.
User friendly features include a top loading feed tray which holds up to 300 sheets plus something you don't see on every folding machine, a manual bypass which allows you to fold stapled sets of up to 5 sheets. Large rubber rollers insures smooth, consistent paper feeding and durable conveyor belts make sure that completed jobs are kept in neat, easy to handle, fanned stacks.

Accepts Multi Sets and Stapled Sets
Paper Weight Conversion Chart Click Here for Paper Weight
Conversion Chart

Please select your preferred download file from below.

For additional resources, please see:

Warranty: For this paper folding machine, Martin Yale's general warranty is 180-days parts and labor. Some restrictions and conditions may apply.

We strongly advise you properly maintain your paper folding machine - please see our Martin Yale 1811 Maintenance Kit for more information.

Manufacturer Name Martin Yale
Model # 1811
Feed Type Friction-fed
Fold Plate/Table Adjustment Manual fold adjustment
Feed Tray Capacity Up to 300
Fold Speed Up to 12,000 sheets/hour
Fold Types Letter, Z-fold, Half, Double-Parallel, Gate, Engineering and Church fold
Manual Paper Feed Up to 5 sheets
Standard Paper Sizes 5" x 5" to 11.69" x 17"
Accepted Paper Weights 16 lb bond to 135 lb index (60 gsm to 240 gsm)
Product Weight 76 lbs.
Dimensions
(WxDxH)
41" x 19.5" x 14"
Voltage 115 Volts; other voltages available
Warranty

UPC 011991018127
Shipping Weight 81 lbs.
Shipping Dimensions 19" x 26" x 15"
