Standard PF-40L Paper Folder (Discontinued)
- SKU: SDMPF-40L
- Sale price
- Limited availability.
- Sale price
- $13,905.00
- Unit price
- per
Call us at (800) 243-9226
FREE FREIGHT SHIPPING within the contiguous U.S.
Features of the Standard PF-40L Paper Folder
- Speed of 390 sheets per minute(A4 single fold);Speed of 270 sheets per minute (A3 single fold); 23,400 sheets/hour (A4 single fold); 16,200 sheets/hour (A3 single fold)
- Powerful air suction feed system
- 6 Standard folds: letter fold, half fold, double parallel fold, z-fold, gate fold and engineering fold
- 10 custom folds in memory, as well as different paper sizes
- Preset counter and preset pause counter
- 1,300 sheet capacity, top fed
- 32 lbs bound to 103 lbs cover
- Rolling base cabinet (included in cost)
FOLD TYPES
 |
Click Here for the Paper Weight Conversion Chart |
Description of the Standard PF-40L Paper Folder
The PF-40L Standard paper folder, with its intelligent automation, is very user-friendly. It has high-volume suction ability and mark-free feeding from digital stock. Memory capacity is high for easy programming of 10 additional custom folds that can instantly be recalled. Non-standard sheet sizes can also be recalled from memory. The 1,300 sheet capacity, top-feed system and push-button control make any fold job easy.
This Standard paper folder is designed for speedy production; the unique suction rotor feeding allows it to easily deliver speeds of up to 23,400 sheets per hour. A simple dial easily adjusts the roller gap for varying sheet thickness, and this unit can handle 32 lbs bound to 103 lbs cover without the need to crease or pre-score. The rolling MT-40 base cabinet is included in the cost. The PF-40L heavy-duty paper folder, with its high adaptability, is a must-have for any print shop.
Strengths
- High memory capacity; up to 20 jobs can be stored, and this is great for executing same folds often.
- Though very speedy, it is quiet, so would be great for any setting.
| Manufacturer Name | Standard |
|---|---|
| Model # | PF-40L |
| Feed Type | Air-fed |
| Fold Adjustment Setting | Automatic fold adjustment |
| Feed Tray Capacity | Up to 1,300 |
| Fold Speed | 23,400 sheets/hour (A4); 16200 sheets/hour (A3) |
| Fold Types | Letter Fold (Tri), Z Fold, Half Fold, Double Parallel Fold, Gate Fold, Engineering Fold |
| Pre-programmed Standard Folds | 6 |
| Programmable Presets | 20 |
| Counter | Yes |
| Accepted Paper Sizes | 4.93" x 5.04" to 12.59" x 24.80" |
| Accepted Paper Weights | 32 lbs to 103 lbs. |
| Weight | 298 lbs. |
| Height | 30.4'' |
| Width | 61.5'' |
| Depth | 24.8'' |
| Voltage | 115 Volts; 230 Volts |
| Warranty | |
| Shipping Weight | 297.7000 |
| Search Terms | standardef, standardef-35, standardef35, ef35, standardfolder, effolder, paperfolder |
