Standard PF-40L Paper Folder (DISCONTINUED)

Standard PF-40L Paper Folder (DISCONTINUED)

Features of the Standard PF-40L Paper Folder

  • Speed of 390 sheets per minute(A4 single fold);Speed of 270 sheets per minute (A3 single fold); 23,400 sheets/hour (A4 single fold); 16,200 sheets/hour (A3 single fold)
  • Powerful air suction feed system
  • 6 Standard folds: letter fold, half fold, double parallel fold, z-fold, gate fold and engineering fold
  • 10 custom folds in memory, as well as different paper sizes
  • Preset counter and preset pause counter
  • 1,300 sheet capacity, top fed
  • 32 lbs bound to 103 lbs cover
  • Rolling base cabinet (included in cost)

The Standard PF-40L paper folder is extremely user-friendly. This letter folder machine's high-volume suction ability and, mark-free feeding and automation enhance performance and with its high flexibility, it is a must-have for any print shop.




Regular price
Sold out
Sale price
$13,905.00
Unit price
per


SKU: SDMPF-40L
Request A Quote

Secured & Safe Checkout :

trust badge

Description of the Standard PF-40L Paper Folder

The PF-40L Standard paper folder, with its intelligent automation, is very user-friendly. It has high-volume suction ability and mark-free feeding from digital stock. Memory capacity is high for easy programming of 10 additional custom folds that can instantly be recalled. Non-standard sheet sizes can also be recalled from memory. The 1,300 sheet capacity, top-feed system and push-button control make any fold job easy.

This Standard paper folder is designed for speedy production; the unique suction rotor feeding allows it to easily deliver speeds of up to 23,400 sheets per hour. A simple dial easily adjusts the roller gap for varying sheet thickness, and this unit can handle 32 lbs bound to 103 lbs cover without the need to crease or pre-score. The rolling MT-40 base cabinet is included in the cost. The PF-40L heavy-duty paper folder, with its high adaptability, is a must-have for any print shop.

Strengths
  • High memory capacity; up to 20 jobs can be stored, and this is great for executing same folds often.
  • Though very speedy, it is quiet, so would be great for any setting.

Manufacturer Name Standard
Model # PF-40L
Feed Type Air-fed
Fold Adjustment Setting Automatic fold adjustment
Feed Tray Capacity Up to 1,300
Fold Speed 23,400 sheets/hour (A4); 16200 sheets/hour (A3)
Fold Types Letter Fold (Tri), Z Fold, Half Fold, Double Parallel Fold, Gate Fold, Engineering Fold
Pre-programmed Standard Folds 6
Programmable Presets 20
Counter Yes
Accepted Paper Sizes 4.93" x 5.04" to 12.59" x 24.80"
Accepted Paper Weights 32 lbs to 103 lbs.
Weight 298 lbs.
Height 30.4''
Width 61.5''
Depth 24.8''
Voltage 115 Volts; 230 Volts
Warranty
Shipping Weight 297.7000
Search Terms standardef, standardef-35, standardef35, ef35, standardfolder, effolder, paperfolder
Q: What is the life expectancy for this folder machine?
A: This is a production caliber machine and thus doesn't really have a life expectancy. As long as parts are available, and you're willing to pay for repairs, it can be kept going for a very long time.
