Duplo DF-755 Paper Folder (Discontinued)
Duplo DF-755 Paper Folder (Discontinued) Folders Duplo

https://www.youtube.com/watch?v=IsDplOv-j5k
Duplo DF-755 Paper Folder (Discontinued) Folders Duplo



Duplo DF-755 Paper Folder (Discontinued)

  • SKU: DUPDF755
  • Max Paper Weight: 145 g/m²
  • Max Paper Size: 11" x 17"
  • Adjustment: Manual
  • Feed Type: Friction
Sale price
Limited availability.
Sale price
$2,500.00
Unit price
per
Request A Quote
Need Advice?
Call us at (800) 243-9226

FREE FREIGHT SHIPPING within the contiguous U.S.

Features of the Duplo DF-755 Paper Folder

  • 3-roller friction feed system, allowing for an extensive variety of paper sizes and weights
  • Simple adjustments for both standard and custom folds
  • Control panel has an LED 4-digit counter with batch and total functions
  • Extended exit tray assures flawless stacking of folded sheets
  • Single sheet feeding auto-adjusts for different weights of paper
  • Auxiliary paper guide for quality cross-folding
  • Load/unload paper from the same side
  • Visual and auditory alerts in case of improper operation
  • Precise Skew and micro-adjustment dials
  • Quick-release roller system for quick and easy maintenance
  • All-metal construction
  • Approved by UL and C UL

Features of the DF-755 Duplo Folder

  • Automatic document folding machine
  • Speed of 120 sheets per minute; 7,200 sheets/hour
  • Fold types: single, double, irregular accordion, letter, accordian, gate, custom, and special right angle in 2 passes
  • For use with 11" x 17" paper, 13 - 80 lbs
  • Auto-feed Friction
  • 500 sheet loading capacity
  • New paper detect sensor for feed tray instead of switch
  • Adjustable receiving roller
  • 2 knobs for fine-tune adjustments to fold setup
  • 4-digit digital display

Fold Types

Letter/Tri/C FoldHalf/Single FoldZ/Accordion FoldDouble Parallel FoldGate/Brochure FoldEngineering/Short Z/Fold-Out/Half-Accordion Fold

Paper Weight Conversion Chart
Click Here for the Paper Weight Conversion Chart
The compact Duplo DF-755 paper folder is easy to use and has the same credibility as Duplo's automatic paper folders. Folding a variety of stock and offering simple charts and controls, this machine folder is sure to be a success anywhere.

Video for the Duplo DF-755


Description of the Duplo DF-755 Manual Setting Paper Folder

The compact Duplo DF-755 manual paper folder is easy to use and budget-friendly, with the same credibility as Duplo's automatic machine folders. Folding a variety of stock and paper sizes at 7,200 sheets an hour, this paper folder is great for any user. Set up for this manual folder is convenient with user-friendly charts. Even better, there is fine-tune adjustment knobs, making minor adjustments for custom folds easy, as well as accurate.

The user can put 500 sheets of paper at once into the feed tray, and 4-digit LCD display enables non-stop, accurate folding of up to 80 lb paper. The Duplo DF-755 offers several fold options: letter, half, double parallel, z-fold (accordion), half accordion and gate. This manual folder also has special cross fold capability; no extra parts are required. Smooth delivery is ensured by the adjustable receiving roller. The DF-755 machine folder by Duplo is sure to be a success anywhere, a church, school, or office.

Strengths

  • Special cross fold capability; no extra parts needed.
  • Folds a wide variety of paper and offers many different folds.
<

FOLD TYPES

Letter/Tri/C FoldHalf/Single FoldZ/Accordion FoldDouble Parallel FoldGate/Brochure FoldEngineering/Short Z/Fold-Out/Half-Accordion Fold

Paper Weight Conversion Chart
Click Here for the Paper Weight Conversion Chart

Manufacturer Name Duplo
Model # DF-755
Feed Type Friction-fed
Fold Adjustment Setting Automatic fold adjustment
Feed Tray Capacity Up to 500
Fold Speed 7,200 sheets/hour
Fold Types Half Fold, Letter Fold (Tri), Z Fold, Double Parallel Fold, Engineering Fold (Short Z)
Pre-programmed Standard Folds 6
Programmable Presets Yes
Counter Yes
Accepted Paper Sizes 5'' x 7'' to 11'' x 17''
Accepted Paper Weights 13 to 80 lbs.
Weight 71 lbs.
Height 21.1''
Width 24.4''
Depth 18.9''
Voltage 120 Volts; other voltages available
Warranty

Shipping Weight 71.0000
Search Terms duplodf755, duplodf-755, duplodf755folder, duplodf-755folder, paperfolder, duplopaperfolder, duplofolder, 755paperfolder, duplo755, df755
