Duplo DBM-120 Bookletmaker - Discontinued Bookletmakers Duplo
Duplo DBM-120 Bookletmaker - Discontinued Bookletmakers Duplo

Duplo DBM-120 Bookletmaker (Discontinued)

  • SKU: DUPDBM120
Limited availability.
$0.00
Request A Quote
Need Advice?
Call us at (800) 243-9226

This product qualifies for Free Ground Shipping within the contiguous U.S.

Basic Specs of the DBM-120

  • Speed: Up to 2,400 sets/hour
  • Sheet size: 7.87'' x 7.87'' to 12.6'' x 17.72''
  • Corner Stapling sheet size: 8.5" x 11"
  • Side Stapling sheet size: 5.47" x 7.87" to 9.09" x 12.6"
  • Paper Capacity: up to 25 sheets of 75 gsm
  • Programs: 10 pre-set and 3 custom
  • Staple heads: 2
  • Staple Positions: 5
  • Electrical: 120 Volts, 60 Hz
  • Dimensions (L x W x H): 28'' x 22" x 23"
  • Weight: 183 lbs.

Features of the DBM-120

  • Low staple indicator
  • Moving clincher stapling mechanism
  • Paper jam detector
  • Side/back jog
  • Adjustable roller pressure & detachable conveyor
  • Automatic size changeover for stapling/folding
  • 2-way interface for Duplo collators
  • Note: Available only while supplies last
The DBM-120 is customized for simple setup and foolproof operation. With the most common applications applications pre-programmed, easy bookletmaking is accessed at the touch of a button.

Description of the Duplo DBM-120 Auto-Setting Bookletmaker

The DBM-120 is customized for simple setup and foolproof operation. With the most common applications applications pre-programmed, easy bookletmaking is accessed at the touch of a button. No timely manual adjustments are necessary. Since the side guides, head stops, staple/fold position stoppers, and machine automatically move to the correct position, the operator can conveniently change from one job to the next in mere seconds.

Manufacturer Name Duplo
Max Sheet/Binding Capacity (20 # paper) 20 sheets
Max Speed 2,400 book/hour
Number of Staple Heads 2
Number of Staple Head Positions 5
Staple Magazine Capacity 5,000
Corner Stapling Yes
Side Stapling Yes
Max Paper Size 12.6'' x 17.72''
Model # DBM-120
Weight 183 lbs.
Height 23"
Width 22"
Depth 28"
Voltage 120 V
Warranty
>> Click Here to View Warranty
Shipping Weight 183.0000
