HSM V-Press 860 P

  • SKU: HSMVP860P
  • GTIN/UPC: 096224657939
  • Mfr. Part No.: HSM6148113

This product has limited availability and/or is build-to-order.
Please call us at (800) 243-9226 or fill out the Request a Quote form, below.

Request A Quote
Need Advice?
Call us at (800) 243-9226

Basic Specs of the HSM V-Press 860 P

  • Voltage / Frequency: 3 x 400 V / 50 Hz
  • Loading Aperture (W x H): 47.04 x 25.59 inches
  • Bale Weight: Up to 507 lbs.
  • Bale Size (L x W x H): 47.24 x 30.70 x max 47.24 inches
  • Cycle Time in Idle Operation (Theor.): 25 seconds
  • Press Chamber Size (W x D x H): 47.04 x 30.70 x 64.56 inches

Features of the HSM V-Press 860 P

  • Rapid stroke technology saves time and money.
  • Double quantity of retaining claws optimize the compression of the pressing material and reduce the number of loading actions.
  • Reinforced press chamber and door lock.
  • Robust mechanical bale ejector chain.
  • High process reliability due to HSM TCS (TorsionControlSystem).
  • Configuration: PET/UBC door with hydraulic door lock.
  • Made in Germany.
The HSM V-Press 860 P is specifically designed to handle PET/UBC bottles with ease.

Description of the HSM V-Press 860 P

Designed specifically to handle PET/UBC bottles, the V-Press 860 P takes on opened/perforated bottles and compresses them into compact bales. The V-Press 860 P is ideal for any industry dealing with a high volume of PET bottles The V-Press can output 1 to 2 bales per hour, these bales can weigh up to 507 lbs. Utilizing a heavy duty bale ejector chain, bales are ejected from the machine directly onto pallets for easy transport.

With the reinforced press chamber and door lock, the V-Press 860 P, there is double the amount of retaining claws typically found in HSM balers that work to optimize the compression process while eliminating the number of tedious loading actions. Users do not need to do more than load, command, wait, and transport bales. The 860 P is flexible and can be modified to crush other materials as well.

Manufacturer Name HSM
Voltage / Frequency 3 x 400 V / 50 Hz
Loading Aperture (W x H) 47.04 x 25.59 inches
Bale Weight Up to 507 lbs.
Bale Size (L x W x H) 47.24 x 30.70 x max 47.24 inches
Cycle Time in Idle Operation (Theor.) 25 seconds
Press Chamber Size (W x D x H) 47.04 x 30.70 x 64.56 inches
Weight 4894 lb
Height 117.5 in
Width 70.75 in
Depth 50.1 in
